GIZMO Microwave Motion Switch
GIZMO Smart motion switch uses microwave motion sensing technology to detect the motion of human body to trigger the load without even touching the switch board. When someone enters the scope of the “GIZMO Motion Switch” it triggers the Load, may be light or any electrical load. When people leave the detection range switch turns off automatically after an interval of time. It has Light control to further automate the load as per day/night to save electricity by not turning load on when it’s not needed.
Contents:
- GIZMO Motion Switch
- Connection wiring clips
- User manual
LUX switch is to adjust day or night work.
- When adjusted to the sun position, the sensor works all day;
- When it is transferred to the moon position, the sensor does not work during the day and automatically enters the working state at nigh
TIME switch is to adjust the sensor delay time
The delay time refers to the time when the sensor leaves the sensing area after the sensor senses the person and the sensor delays the time.
Feature:
- Mini size and light weight, easy to install and use, flexible operation. Affordable retrofit design to suit the need without changing current setup. Electricity saving by 50-70% by turning the load off when not needed. Adjust the light soft and stable, no flickering. Works with LED lights 170° wide sensing angle, 4-6 meters long sensing distance. Adjustable delay-time (10s - 15min). Photosensitive light control selections (≤2Lux to 2000Lux). Specification:
- Mini size and light weight, easy to install and use, flexible operation.
- Affordable retrofit design to suit the need without changing current setup.
- Electricity saving by 50-70% by turning the load off when not needed.
- Adjust the light soft and stable, no flickering. Works with LED lights
- 170° wide sensing angle, 4-6 meters long sensing distance.
- Adjustable delay-time (10s - 15min).
- Photosensitive light control selections (≤2Lux to 2000Lux).
Specification:
- • Operating Volt: AC 220-250V 50Hz-60Hz.
- • Load power: Up to 1200W Max
- • Ambient Light: 10-2000Lux (Adjustable)
- • Load type: Incandescent lamp, LED light, CLF, fans, etc
- • reach:1-8m(radii.), adjustable
- • HF system: 5.8GHz CW radar,ISM band
- • Detecting distance: 3~12 Mtr
- • transmission power:<10mW
- • Detecting Angle: 360 Degree
- • Instillation Hight: 2.2-4 Mtr
- • Motion Detection Speed: 0.6~1m/s
- • Power Cusumption:0.1W (static) & 0.4(Work)
- • Working Humidity: less than 93%RH
- • Delay: 10 Seconds -15 Minutes (Adjustable)
APPLICATION:
- Schools/Colleges
- Offices
- Manufacturing plants
- Hospitals
- Restaurant
- Society parking
- Houses/ flats
- Factories
- Hotels
